Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 336
d connected to the dif-ferent rim sections as shown in Fig. 520. The hubin this case is made in two sections and the rim insix sections, to each of which latter two arms areflanged. The sections of both hub and rim are held to-gether by bolts passing through projecting flanges,as shown in Fig. 520… … 366 ROGERS DRAWING AND DESIGN. pieces made of mild steel, which are shrunk into re-cesses of similar shape, making a rigid joint. A different type of reinforcement is illustrated indetail in Figs. 521, 522 and 523. Here, instead ofthe I-shaped piece, a wrought iron link is substituted,which is…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
