examjile of the same with a fillet above. The tangent A B, and the greatest pro-jection of the moulding at C being given, from A draw A D E, perpendicular; from C draw C Dparallel to A B, making D E and D A equal. Having divided C B and C D into an equalnumber of parts, draw lines from A to the… … MOULDINGS AND ORNAMENTS. 117 varying from the circle. The Eoman Ovolo and Gavetto are never found in GrecianArchitecture, nor the Greek Echinus in Roman; the others they possess in common. An assemblage of essential parts and mouldings is termed a profile. On thechoice, disposition, and…
