the path of the crank pin center.Divide this circle into any number of equal divisions, in this case,twelve, at points 1, 2, 3, etc. It is evident that if a line be drawnfrom any one of these points, as 2, perpendicular to the line AB,that, neglecting the angularity of the connecting rod, the… … Fig. 58. Valve Ellipse Diagram Showing Information to be Obtained from its Analysis to the same scale as that of the circle ABCD and sweep the arcsfrom the points 1,2,3, etc., with the center on the line A B produced.Now representing the path of motion of the valve by the line H F,drawn…
