is in the proper positionfor producing rotation in a counterclockwise direction. Themechanism is arranged so that either of these eccentrics may bemade to operate the valve, and rotation in either direction pro-duced at will. A Stephenson link reversing gear is illustrated in Fig. 117showing the… … 2 186 STEAM ENGINES is the same as those shown in Fig. 116. The eccentric A is in theproper position for producing rotation in a clockwise direction,and B is in the proper position for producing rotation in a counter-clockwise direction. Each eccentric has its own eccentric rodconnected to one end…
