The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 437
Fig. 281. — Van den Ker-chove Piston-lift Valves. 420 VALVE GEARS AND GOVERNORS. [Chap. VIII. … Fig. 283. — The Collman Releasing Gear, Fig. 284. — Steam Valve and Gear, 42 byHigh-pressure Cylinder of Compound 60 in. high-pressure cylinder of en- Engine. Scale 1 to 8. gines in Subway Power House, New York. Scale 1 to 18. the exhaust eccentric OE2 has about the same angle of advance (froma…
Steam-engines · Steam-turbines
