wall and piston, and the joint ismade steam-tight by the packing rings, which are set into grooves cutin the piston rim, and are pressed outward either by their own elasticityor by light springs placed beneath them. The piston rod, securely § 2 (c)] CONSTRUCTION AND WORKING OF THE ENGINE. fastened… … Fig. 5 — Engine in Fig. 2, Cross Section at Guides. 1. Engine bed. 2. Bottom guides. 3. Top guides. Crosshead.Wrist pin.Oil guard. 7. Rocker bracket. 8. Rocker arm. 9. Oiltank.
