The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 24
Fig. 5 — Engine in Fig. 2, Cross Section at Guides. 1. Engine bed. 2. Bottom guides. 3. Top guides. Crosshead.Wrist pin.Oil guard. 7. Rocker bracket. 8. Rocker arm. 9. Oiltank. … Fig. 6. — Engine in Fig. 3, Cross Sections, A at middle of guides, B in front of guides,both looking toward cylinder. 1. Engine bed. 5. Wrist pin. 9. Governor base and 2. Guides. 6. Valve bonnets. drive. 3. Crosshead. 7. Valve stem. 10. Steam rocker. 4. Crosshead shoes. 8. Wrist plates. 11. Exhaust…Steam-engines · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
