particles being of much greater specificgravity than the steam, are propelled by their own momentumto the bottom of the separating chamber. Note.—With the separation shown in Fig. 371, removal of the mois-ture depends solely upon the whip-snap action which accompanies thecurrent-reversal. With the… … Direction Of >Steam CurrentDrainage Ducts LeadingFrom Troughs To BottomOf Separating Chamber Fig. 371.—Happes Re-verse-Current HorizontalExhaust-Steam Separator. . Drain-•Receiver -Welded Joint Fig. 372.—Welderon Re-verse-Current HorizontalReceiver-Separator. Outlet- OutletTube]Hooded Guard to…
