Structural analysis and design of airplanes (1920)
United States. Army. Air Corps · [Washington] · leaf 235
Fig. 142. Section of Stabilizer Spar on Curtiss Kirkham Half Way Out … Fig. 143. Maximum Section of Stabilizer Spar on Curtiss Kirkham 18-T 216 Art. 147 Bracing The entire load on the horizontal and vertical surfaces is carried inbending by the spars in the fixed surfaces acting as cantilevers in com-bination with the torque tubes in the elevator and rudder. The…
Airplanes
