Structural analysis and design of airplanes (1920)
United States. Army. Air Corps · [Washington] · leaf 65
Fig. 26. Wing Tips ^3£ … Art. 34 Location of Interplane Struts would be injurious. Furthermore, locating a front wire at such pointwould result in a large drag compression in the front spar whenit was most heavily stressed. The practice of using external dragwires is not recommended. They make the wing structure…
Airplanes
