Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 159
long. Three lugs project from eachedge of this bed plate and are slottedto receive \\ in. anchor bolts. The bear-ings are the same at both ends of the bridge, and although bothwere free to move longitudinally with temperature variations,no indications of such movement were noticed when thesedetails… … Beoring at End of 60 Girder.Gokteik Viaduct. SIMPLE SLIDING ENDS 143 umns. The 60-f t. girders being deeper than the 40-ft. girders,have their webs notched and horizontal flange angles rivetedto them to give them bearing with the 40-ft. spans on the samecap plates, and still keep the top flanges of…
Bridges
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
