int where thecenter line of the lower portions must meet it. It willbe seen that if the center line of the lower portion hadbeen produced, it would cut the perpendicular below So COMMON-SENSE HANDRAILING A. Then the pitch must be altered to lengthen as fewbalusters as possible. This must be done… … Fig. 19. Fig. TQ shows the face mould for Fig. i8, obtained lothe same way as those for Fig. i on the last page. Fig. 20 shows how the usualthickness allowed for the wreathis obtained. Where there is adifferent bevel for each end theone with the more acute angleis used. Fig. 21 is the plan of…
