Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 319
inders. At Fig., 138, A, 318 Aviation Engines the bottom view of a twelve-cylinder engine with bottomhalf of crank case removed is given. This illustratesclearly the arrangement of main bearings when the crank-shaft is supported on four journals. The crank-shaftshown at Fig. 138, B. is a… … Main Bearing No,Zy A ^■■-Balance weights bolted on
Airplanes
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
