Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter (1887)
Wightwick, George · London, Lockwood · leaf 35
pyramid; and verti-cally also, since x agives the distancefrom the axis x x onthe picture. Thusthe distances from therespective axes x xand Y Y are deter-mined and the pointd fixed. Any otherpoint may be deter-mined in the same manner, and the pyramid completed.Theory of Lines and Planes.—The… … HINTS ON PERSPECTIVE. 23 every position, and it is sufficient to determine theperspective positions of two points in it and join them. Planes or lines parallel to the plane of picture have novanishing points, or are assumed to have none. Planes or lines inclined to the picture plane vanish inthat…
Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
