Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 539
Fig. 333- Schenectady Intercepting Valve in Compound Position. through the regulating and intercepting valve-working divi-sion on the line 5, 5 of Figs. 333 and 334. Fig. 337 is asimilar section on the line 6, 6 of the same figures. Fig. 338is a vertical lengthwise section through the regulating… … Fig. 334. Schenectady Compound, Working both Cylinders withLive Steam (see page 528). SCHENECTADY COMPOUND. sion on the line 7, 7 of Figs. 332,, 336 and 337; Fig. 339, avertical cross section through the intercepting valve on theline 8, 8, of Fig. 335. The feathered arrows show the courseof the…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
