e. STEAM POWER APPLIANCES. 8l 164. BALANCED PISTON VALVE. The segmental packing,E, is held close to the cylinder wall by the pressure of the steam which enters through holesin the flange, E,shown by the circlesbelow the cylinder.e, live steam connec-tion to receiver oflow-pressure cylin-ders, a… … By-passValve
