alidea of the outside appearance. Floor plans represent views seen from above when a horizontalsection is taken through the building, these horizontal sections beingcut through the windows and doors. The floor plans show clearly the plan of arrangement of thevarious rooms, the positions of doors… … LESSOX Xo. 37—Continued.
