Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 111
there are two sets of recipro-cating pistons, one in a horizontal plane and the other in avertical plane. Each piston is really a part of the frame whichslides steam-tight in the casing which it fits. The doublemotion enables the components of rotary motion to be pro-vided for in the reciprocating… … PLAN Fig. 46.—Be Laval Turbine.
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
