le-bracket at Meeting of Straightand Concave Walls Fig. 21. C B, G IT into the same number of equal parts; throughthe divisions of C B draw the lines CD, 1 d h, 2 e i, &c.,perpendicular to A B and through those of G H draw PRACTICAL SOLUTIONS 157 the parellel lines, part straight and part… … Angle-bracket at Meeting ot Coves ot Equal Heightbut Unec|ual Projection Fig. 22. Fig. 22 shows the method of finding the angle-bracketat the meeting of coves of equal height but unequalprojection. The height C B is equal to G H, but theprojection B A is greater than H I. 158 MODERN CARPENTRY Fig.…
