DREDGING AND DItEDGING-MACHINES. … W=P K1 is a mangle-wheel, which gives an alternate circular motion to the cams A, which are driven by apulley and shaft fl, which has a pinion on the lower end geering into the mangle-wheel. The pulleyf1 is driven by a belt from the upright D. £ is a friction-roll attached to a lever pt which…
