641. SHORT-RANGE WALKING BEAM. By the interlocking linkage the cyHnder andcrank can be brought close together. None of the motions in this linkage areparallel. The piston rod is the guide to thelast link. … 642. TURNING A SQUARE BYCIRCULAR MOTION. A device onehundred and fifty years old. Not an eco-nomical device for square work, but ap-plicable for irregular and fluted work. Pos-sibly the original idea of the rose lathe.. 643. DOUBLE-LINK UNR^ERSAL JOINT. This arrangemeiit allows of a large deviating…
