Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 396
Fig. 29a 183. The Eccentric-rod and Valve-stem.—The compo-nents of the crank-motion of the eccentric which are notneeded to move the valve must be provided for as in the main-connecting-rod. Hence there will be a joint of some sortbetween the eccentric-strap and the stuffing-box at which…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
