Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 273

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 273
1046. EQUALIZING TENSION SPRING ANDLEVER.—The bell-crank lever equalizes the tension ofthe spring by its varying position. Its long arm is on afixed pivot. 1047. ALTERNATING RECTILINEARMOTION from studs on a rotating disc. Thebar is carried forward by the stud on the discstriking the projection on… … 1048. TRAVERSE BAR, operated by aslotted lever. The upper pin being fixed ormade adjustable for proportion to the move-ment of the lower pin, any desired movementof the traverse bar may be made. 1049. RECTILINEAR MOTION by themovement of a slotted lever with one end pin-ioned. A belt shipper…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
