, aud well spiked. Fig. 137 is a cross-section of a large dairybarn; it clearly shows the general arrangementof stalls, mangers, gutters, etc., all constructedout of cement laid on solid ground. The stallpartitions are built up out of wrought-iron barsand pipes, leaving nothing to get out of order… … Fig. 138. Self-Supporting Roof Construction. out of plank; and the roof is self-supporting,without posts or purlins, through each set ofrafters being braced, forming a continuous archfrom one sill to the other. This roof gives an enormous capacity to the 262 FRAMING hay room, and is well braced…
