A treatise on gear wheels (1904)
Grant, George B. (George Barnard), 1849-1917 · Boston, Grant gear works, incorporated · leaf 106
Formation of Beale gear.Fig. 167. … UncorrectedBeale gears. Fig. 169. NDEX. Section. Addendum 39 Arc of Action 25 Axoids 7 Backlash 41 Base Circle 16, 54 Beales Gears 177 Beales Treatise 4 Begin at the Beginning 3 Bevel Gears 6, 7, 8, 152, 154 to 169 Boxs Mill Gearing 4, 51 Brown & Sharpe Co.s Treatise 4 Cast Gearing, Friction 49…Gearing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
