Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 181
FRAMING OF INNER BENTS … V w w^ CONSTRUCTION AT ENDS PLATE 167—PLANK FRAMING AND SELF-SUPPORTING ROOFS FOR BARNS Diagrams showing end framing, center bentconstruction and side wall framing for theWing system of joist frame barn building.Side walls should be 18 to 20 feet high; and un- less the barn is to be more than 50…
